ADL3000-E Three-Phase Multi-function Energy Meter With UL Certificate

ADL3000 is a smart meter designed for power supply system, industrial and mining enterprises and utilities to calculate the electricity consumption and manage the electric demand. It features the high precision, small size and simple installation. DTSD1352 can be used in all kinds of control systems, SCADA systems and energy management systems. All meters meet the related technical requirements of electronic power meter in the IEC62053-21、IEC62053-22 standards.

Get a Quote Contact Us

Fast And Safe Logistics
Sample Available

ADL3000-E

IEC62053-21、IEC62053-22

kWh: Class 0.5S,kVarh:Class 2

AC 3×220/380V，3×380V，3×57.7/100V，3×100V

3×1（6）A，3×10（80）A

U、I、P、Q、S、PF、kWh、kvarh

RS485(MODBUS-RTU)

Features

●Rated U and I

AC 3×100V, 3×380V, 3×57.7/100V, 3×220/380V; 3×1(6)A, 3×10(80)A

●Accuracy

kWh: Class 0.5S,kVarh:Class 2

●Display

8 digits LCD display U, I, P, Q, PF, kWh and other energy consumption, Power measure (999999.99kWh)

●Starting current

Direct connect: 0.004Ib

Connect via CT: 0.001ln

Technical Parameters

Voltage	Reference voltage		357.7/100V,3220/380V,3100V,3380V
	Reference frequency		50Hz
	Consumption		<10VA(Single phase)
Current	Maximum current		6A,80A
	Starting current		Direct connect:0.004lb
			Connect via:0.001In
	Consumption		<1VA(Single phase rated current)
Measurement	Accuracy		Class 0.5
performance	Standards compliant		IEC 62053-22:2003
Pulse		Pulse width	80+20ms
		Pulse constant	400imp/kWh
			6400imp/kWh
Communication	Interface		RS485
	Protocol		Modbus-RTU
Temperature range	Work	-25°℃~55°℃
	Storage	-40°C~70°C
Humidity		≤95%(No condensation)
Altitude		<2000m

Wiring

Network
